| Input Voltage | Output Voltage | Output Current | Power | Mounting Style |
| 36-75Vdc | 12Vdc | 8A | 96W | DIN Rail |
FEATURES:
-
High Efficiency & Power: Delivers greater than 89% efficiency with stable 96W power performance for independent supply systems
. -
Voltage Compensation: Step-down converter that compensates for fluctuations from unregulated 48V power supplies or long cables via reliable galvanic isolation
. -
Adjustable Output & Protection: Features a potentiometer-adjustable 12V DC output (5V–15V) with built-in short-circuit and overload protection
. -
Dynamic Load Reserve: Utilizes a standard load reserve capable of delivering a surge current up to 12A (150% of rated current) for a 5-second boost duration
. -
Parallel Connection Capable: Supports direct parallel connection of up to 3 units for flexible system scalability
. -
Certified Safety Standards: Built to Protection Class III and fully compliant with DIN EN 61204-3, IEC 61010-1, IEC 61010-2-201, and RoHS guidelines
.
