| Input Voltage | Output Voltage | Output Current | Power | Mounting Style |
| 14-32Vdc | 48Vdc | 10A | 480W | DIN Rail |
FEATURES:
-
High Efficiency & Power: Delivers up to 91% efficiency with above-average power performance (480W) for independent supply systems.
-
Voltage Compensation: Compensates for fluctuations from unregulated power supplies or long cables via galvanic isolation to avoid ground loops.
-
Adjustable Output & Protection: Features a potentiometer-adjustable 48V DC output (45V–56V) with built-in short-circuit protection and an integrated ORing MOSFET for decoupling internal short circuits.
-
Peak Load Reserve: Utilizes advanced DCL technology to deliver a 500% peak load reserve of rated current for a 15 ms boost duration, or a 200% reserve for up to 5 seconds.
-
Parallel Connection Capable: Supports direct parallel connection of up to 10 units for redundancy setups or flexible system scalability.
-
Certified Safety Standards: Built to Protection Class III (with no ground connection, for SELV) and fully compliant with RoHS safety guidelines.
