| Input Voltage | Output Voltage | Output Current | Power | Mounting Style |
| 14-32Vdc | 24Vdc | 10A | 240W | DIN Rail |
FEATURES:
-
High Efficiency & Power: Delivers up to 91% efficiency with above-average power performance for independent supply systems
. -
Voltage Compensation: Compensates for fluctuations from unregulated power supplies or long cables via galvanic isolation
. -
Adjustable Output & Protection: Features a potentiometer-adjustable 24V DC output (22.5V–28.8V) with built-in short-circuit and overload protection
. -
600% Peak Load Reserve: Utilizes advanced DCL technology to deliver 600% of rated current for a 15 ms boost duration
. -
Parallel Connection Capable: Supports direct parallel connection of up to 10 units for flexible system scalability
. -
Certified Safety Standards: Built to Protection Class III and fully compliant with EN 61558-2-16 and RoHS safety guidelines
.
