QS40.241 PULS 24Vdc 40A DIN Rail Power Supply
| Output Voltage | Output Current | Power | Mounting Style | Input |
| 24Vdc | 40A | 960W | DIN Rail | 85-276Vac |
FEATURES:
- AC 100-240V Wide-range Input
- Width only 125mm, Weight only 1.9kg
- 94.6% Full Load and Excellent Partial Load Efficiencies
- 50% BonusPower, 1440W for up to 4s
- 110A High Peak Current for 10ms for Easy Fuse Tripping
- Safe HiccupPLUS Overload Mode
- Active PFC (Power Factor Correction)
- Negligible Low Input Inrush Current Surge
- Full Power Between -25°C and +60°C
- Current Sharing Feature for Parallel Use
- Internal Data Logging for Troubleshooting Included.
- Remote Control of Output Voltage
- DC-OK Relay Contact
- Shut-down Input
- ATEX and IECEx Approved
